Cool-Master Speed-Commander 1400 SEL High Speed Door

This door is ideal for energy conscious, 24/7/365 applications in agricultural, medical, and cold storage facilities.

Cool-Master Speed-Commander1400 SEL, Spectrum Facility, AZ

Hormann Speed-Commander 1400 SEL Cool-Master

Fabric High Performance For Interior Applications

High Speed Insulated Fabric Doors

Features and Benefits:
  • Maximum dimensions up to 14’0” wide x 16’0” high.
  • Panel material: 3 mm thick gray foam panel material maintains flexibility in areas over +33˚ F and helps keep condensation to a minimum in cooler to ambient areas.
  • An optional unheated air curtain is available. The blower turns on when the door is activated and deactivates minutes after the door is closed.

 Hormann Speed-Commander 1400 SEL Cool-Master

Cool-Master Speed-Commander1400 SEL, Spectrum Facility, AZ
Foam Panel Material for Optimum Energy Savings

This is the ideal door for energy conscious, 24/7/365 applications in agricultural, medical, and cooler distribution facilities. The fast operating speeds allow constant traffic flow without compromising energy control and efficiency. An advanced 3 mm thick gray foam panel material maintains the flexibility to +33 degrees F and helps to keep condensation to a minimum in cooler to ambient areas. Our unique sectional panel design makes it easy to replace panels for minimal downtime.

Built-In Light Grid for Added Protection

Standard on the Cool-Master is a light grid built into the guide tracks up to 8’0″ high. Completely free of coil cords, the light grid provides a thorough wall of protection for personnel and equipment in the doorway, as compared to other doors that use only photocells. The light grid also eliminates the need for a panel reversing edge, which is typically vulnerable to damage and reduces maintenance and downtime. Full perimeter draft seals provide additional environmental control.

Food-Master Speed-Commander1400 SEL Spectrum Facility
Cool-Master Speed-Commander1400 SEL, Spectrum Facility, AZ
Smart Start™ NXT NEMA 4X Control Box Simplifies Installation.

The Cool-Master comes with the next generation Smart Start™ NXT NEMA 4X UL control box, which accepts 208 v to 575 v / 3-phase / 60 Hz input voltage. The updated control box has a simplified wiring configuration, is more powerful, and has fewer components and cables than the original Smart Start™.

Application / Size:

Interior applications: up to 14’0″ wide x 16’0″ high.

Panel:

3 mm thick foam fabric connected with heavy-duty aluminum profiles.

Vision:

Optional: Full-width x 35″ high, clear PVC, starting at approximately 52″ from the floor.

Guide Tracks:

Standard: Heavy-duty, 12 gauge, galvanized steel with removable front covers. Guide tracks are 6″ wide x 3-1/2″ deep with vinyl draft seal and have a light grid built in up to an 8’0″ high.

Optional: Stainless steel.

Direst-Drive Motor

Standard: Compact, self-monitoring direct-drive motor has a patented built-in catch system and is maintenance-free.

Operating Speed:

Opening: Up to 80″ per second.

Closing: 30″ per second.

Colors:

Interior applications only: Gray

Safety Devices:

Standard: SoftEdge bottom profile with integral radio crash switch immediately stops the door upon accidental impact. Up to an 8’0″ high light grid built into the guide tracks.

Control Box:

Standard: Smart Start™ NXT NEMA 4X UL 3-phase. (1-phase available)

Consult factory: Smart Start™ NXT HFCB NEMA 3 Non-UL (1-phase, 230 v only).

Optional UPS Emergency Battery Pack: UPS Emergency battery pack Non-UL – Automatic door opening in case of power failure (With HFCB 1-ph control box only).
